Full Automatic Toroidal Core Winder Machine for Silicon Steel Transformer Wound Cores Max. Od 250mm

Collect
Description
This toroidal transformre core winding machine is specially designed for winding toroidal wound cores from CRGO electrical silicon steel full automatically. It has flexible function for various toroidal wound cores:
This machine stops Panasonic PLC control system, full closed-loop control all the procedure, including clamping, fixing, pressing, winding, cutting, welding, releasing, etc.
This machine adopts 5 servo motors driving: |toroidal transformer core winding machine|
* Servo motor for cutting device tracking (non-stop) |toroidal transformer core winding machine|
* Servo motor for cutting down CRGO strips with max. thickness 0.5mm (with reducer)
* Servo motor for spindle winding (with reducer) |toroidal transformer core winding machine|
* Servo motor for flapping & ejecting finished cores |toroidal transformer core winding machine|
* Servo motor for clamping & feeding strip to pin on spindle |toroidal transformer core winding machine
No.
Item
Data
1
Suitable ribbon width
10-100mm
2
Suitable CRGO ribbon thickness
0.12~0.50mm
3
Suitable Permoalloy ribbon thickness
0.1~0.35mm
4
Suitable magnet core ID
Min. 30 mm / Max. 180mm
5
Max. magnet core OD
250mm
6
Main spindle speed
Max. 3000rpm
7
Magnet core ID/OD tolerance
+/-0.5mm
8
Magnet core height evenness
+/-0.1mm
9
Laser generator power
200W
10
Total electric power
6kW
11
Max. ribbon reel weight
1000kg
12
Main machine dimension
About 1950 x 850 x 1600mm
13
Chiller dimension
About 700 x 500 x 800mm
14
Laser generator dimension
About 1200 x 700 x 1000mm
15
Total weight
About 2200kg


Main feature
- Auto feeding, auto winding, auto cutting, auto welding, auto releasing
- PLC control, HMI operation
- Laser welding, no damage to CRGO strip
- Motorized elevating worktable
- Special water chiller for cooling

- Carbide alloy cutting blade, long life
- Auto decoiling CRGO strips
