Automatic Dry Type Transformer Foil Winding Machine (Model BRJ1400-2) | Copper & Aluminum Strip Coil Winding EquipmentThe BRJ1400-2 is engineered for high-efficiency winding of dry-type transformer foil coils using copper or aluminum strips. It supports one or two layers of foil conductor with simultaneous insulation material (paper/film) winding. Equipped with TIG welding, electric disc shear cutting, and an advanced edge alignment system, it ensures straight, smooth coil edges and superior electrical performance. Key highlights include a 1400mm max foil width, 1000mm finished coil OD, dual decoilers for conductor and insulation, pneumatic expansion shafts, and a 10-inch industrial touch screen with PLC control. The machine integrates foil deburring, cleaning, end-fill strip feeding (8 stations), and automatic welding for continuous production. Designed for precision and ease of use, it delivers consistent layer alignment, reduces manual intervention, and meets the demands of modern power industry equipment manufacturing.
Collect
Description
1. Overview The BRJ1400-2 Automatic Dry Type Transformer Foil Winding Machine is specialized for winding transformer foil coils and similar products. The conductor can be copper or aluminum strip. The system handles one or two layers of foil with one or two layers of insulation material. Bus bars are welded using TIG welding. Automatic foil edge alignment ensures coil edges are straight and smooth. The PLC-based control system with a touch screen offers intuitive operation. 2. Key Technical Parameters
3. Core Advantages & Features ① Precision Winding & Edge Alignment Automatic foil edge alignment system guarantees straight, smooth coil edges. Imported PLC control ensures accurate layer registration and tension management for copper/aluminum strips. ② Dual-Layer Capability Winds one or two layers of foil conductor with one or two layers of insulation simultaneously, increasing production efficiency and coil quality. ③ Advanced Welding & Cutting TIG welding for bus bars ensures high conductivity and strong joints. Electric disc shear provides clean, precise cutting. Foil deburring and cleaning systems maintain surface integrity. ④ Intelligent Control 10-inch industrial touch screen with PLC enables easy operation, real-time monitoring, and turn counting (0–9999.9). User-friendly interface suitable for skilled and unskilled operators. ⑤ Robust Mechanical Design Main frame, winding unit, foil/insulation decoilers, pneumatic expansion shafts, and 8-station end-fill strip feeder. Stable winding spindle (80×80×1750mm) supports heavy coils up to 1000mm OD. ⑥ Comprehensive Auxiliary Systems Includes cleaning system, cutting system, deburring, edge alignment, automatic welding, electronic control, and pneumatic systems for continuous, automated production. 4. Main Components
5. Application Scope
6. After-Sales Service
→ Request a detailed quotation, technical datasheet, or factory demonstration today.
