CNC Automatic Circular Saw Blade Sharpening Machine | HSS & Manganese Steel Saw Grinder (Model YCJ-A6)

Engineered for efficiency, the YCJ-A6 4th-gen automatic grinder delivers intuitive operation and precise saw blade repair. Grind high-speed steel (HSS) and flying saw (manganese steel) blades with adjustable cutting angles, tooth depth, and pitch (3-80mm). Supports left/right, arc, triangular, and high-low teeth. The tilting handpiece allows chamfering without wheel change. With automatic tooth dialing, compression, and grinding linkage, it ensures consistent sharpness and extends blade life.

Key Highlights:

  • Wide Compatibility: Ø120-600mm blades, HSS & manganese steel.

  • Multi-Tooth Grinding: Left/right, arc, triangular, high/low teeth.

  • Stepless Grinding Speed: 2800rpm wheel speed, customizable feed.

  • Tilting Head: Chamfer without changing grinding wheel.

  • Auto Mechanical Linkage: Auto dialing, compression, grinding, return.

  • Robust & Compact: 850W power, 168kg weight, 15150 diamond wheel.

Achieve superior blade sharpness.


Collect
Description

1. Overview

The YCJ-A6 (MCJ-05 4th Gen) Automatic Circular Saw Blade Sharpening Machine is a surface grinding solution for power drill and industrial saw blades. With a straightforward structure and simple operation, it precisely restores saw tooth geometry. Change cutting angle, tooth type, and depth to easily grind sharp blades. Suitable for high-speed steel (HSS) and flying saw (manganese steel) blades, it handles left/right, arc, triangular, and high/low teeth. The handpiece tilts up/down for chamfering without wheel replacement.

2. Key Technical Parameters

No.

Item Name

Specification

1

Model

YCJ-A6

2

Power Supply

Custom Requirement

3

Power

850W

4

Saw Web Diameter

120 - 600 mm

5

Dial Tooth Pitch

3 - 80 mm

6

Grinding Speed

Stepless Speed Regulation

7

Grinding Wheel Spec

150×32×10 mm (Single Bevel Diamond Wheel)*

8

Grinding Wheel Speed

2800 rpm

9

Weight

168 kg

10

Package Size (L×W×H)

870 × 639 × 1310 mm

Note: Original spec "15150" interpreted as 150mm OD based on standard grinding wheel dimensions.

3. Core Mechanisms & Advantages

① Automatic Mechanical Interlock Linkage

The machine completes saw blade grinding via full mechanical linkage: saw tooth feeding → cylinder compression → dial needle return → grinding wheel mechanical feed → grinding → return → cylinder release → tooth feed. Automatic reciprocating motion achieves efficient blade grinding.

② Precision Grinding Functions

  • Saw Blade Fixing Mechanism: Ensures stable positioning.

  • Automatic Dialing Sawtooth: Accurate tooth pitch feeding (3-80mm).

  • Automatic Compression: Cylinder compresses blade during grind.

  • Grinding Wheel Mechanism: 2800rpm diamond wheel, stepless speed.

  • Electrical Control: Simple panel, easy to learn.

  • Cutting Fluid Cooling: Integrated cooling for heat dissipation.

③ Versatile Tooth & Material Grinding

Grinds HSS and manganese steel blades. Supports various teeth: left/right, arc, triangular, high/low. Adjust grinding time per cutting requirements.

④ Tilting Handpiece Design

Head tilts up/down; no wheel change needed for chamfering. Enhances flexibility for different tooth geometries.

⑤ Durable & Cost-Effective

Robust construction (168kg), compact footprint (870×639×1310mm package). Quality and economical, ideal for blade maintenance workshops and industrial production.

4. Application Scope

  • Saw Blade Maintenance: HSS circular saw blades, flying saw (manganese steel).

  • Industrial Cutting Tools: Power drill bits, metal cutting blades.

  • Woodworking & Metalworking: Blades for circular saws, flying saws.

  • Workshops: Blade repair, sharpening service, manufacturing plants.

→ Contact our engineering team for a detailed quotation, technical layout, or factory demonstration.
