1. Overview
This automatic panel saw is specifically dedicated to PMMA, MS, PS, Plexiglass, Acrylic, Plastic, and high-quality wood panels. It adopts gear rack driving, double servo control, and a simplified control system, making it suitable for both skilled and unskilled operators while maintaining industrial-grade precision.
2. Key Technical Parameters
Item | YT-280 | YT-330 |
|---|
Sawing Length × Width | 2680 × 2550 mm | 3100 × 3280 mm |
Sawing Speed | 0 – 80 m/min | 0 – 80 m/min |
Feeding Speed | 0 – 60 m/min | 0 – 60 m/min |
Sawing Height (Max) | 80 mm | 80 mm |
Main Saw Motor | 15 kW | 15 kW |
Total Power | 21.7 kW | 21.7 kW |
Air Floating Power | 1.5 kW | 2.2 kW |
Feed / Sawblock Servo | 1.5 kW (each) | 1.5 kW (each) |
Reducer Model | RV63 | RV63 |
Main Saw Blade (OD) | 350 – 380 mm (Shaft 30mm) | 350 – 400 mm (Shaft 30mm) |
Slot Saw Blade (OD) | 180 mm (Shaft 25.4mm) | 180 mm (Shaft 25.4mm) |
Net Weight | 3800 kg | 4500 kg |
Overall Dimensions | 5350 × 5150 × 1700 mm | 5950 × 5650 × 1700 mm |
3. Core Advantages & Features
① Precision & Control System
Panasonic PLC & Servo: Reliable Japanese Panasonic servo motors and PLC controller ensure stable, high-speed cutting.
HD Touch Screen: Intuitive interface with operating hints, troubleshooting guide, manual editing, and simulation of cutting plans. Compatible with barcode management/automation software.
German Electronic Ruler: 0.01mm resolution for precision compensation; imported CNC automatic positioning ruler eliminates artificial errors.
Cutting Straightness: < 0.06mm with imported guide rails, heavy-load capacity.
② Material Handling & Protection
Air Floating Table: Steel ball type air floating loading table ensures smoother movement, avoiding board scratching (ideal for acrylic/plastic surfaces).
Side Aligning System: Fixes panel width, adjusts pressure by thickness/weight, preventing movement/shaking during sawing.
Special Clamps: Acrylic-purpose clamps for small materials; flexible "two fingers" structure (min. plywood 20mm); 7 pneumatic grippers (min. hold 45mm).
③ Mechanical Design & Efficiency
Gear Rack Drive: Imported high-precision rack & pinion for saw carrier; automatic pull-back based on next cutting length reduces idle time.
Automatic Feed: Panasonic servomotor-driven grippers reduce labor intensity.
Saw Carrier: Max cutting speed 60m/min (sawing speed up to 80m/min), stable movement.
Online Fault Detection: Equipped with automatic detection and remote maintenance support.
④ Application Flexibility
Handles PMMA, MS, PS, Plexiglass, Acrylic, Plastic, and wood panels. Process flexible for various sheet sizes with high precision and heavy load capacity.
4. Main Components & Brands
Servo & PLC: Japan Panasonic
Electronic Ruler: German brand (0.01mm)
Guide Rail: Imported brand (high precision, heavy load)
Reducer: RV63
Touch Screen: HD, with full control system
Pneumatic Grippers: 7 pcs for automatic feeding
Air Floating System: 1.5 / 2.2 kW
5. Application Scope
Acrylic / Plexiglass / Plastic sheet cutting
Signage, advertising, furniture panels
Industrial PMMA / PS fabrication
Wood panel / plywood processing (min. 20mm)
Achieve high-efficiency, scratch-free, and ultra-precise panel cutting. → Contact our engineering team for layout, demo, or quotation.
